XG(S)-PON+10GE+4GE+1USB3.0 ONT

○ Hardware Parameter

Dimension

180mm*120mm*34.5mm (L*W*H)

Operating condition

Operating temp: -10 ~ +55°C

Operating humidity:5 ~ 95% (non-condensed)

Storing condition

Storing temp: -40 ~ +70°C

Storing humidity: 5 ~ 95% (non-condensed)

Power adapter

12V/1A

Power supply

12W

Interface

1*10GE+4*GE+1*USB3.0

Indicators

PWR, PON, LOS, WAN, LAN1~5, USB

○ Interface parameter

PON Interface

• SC single mode, SC/UPC connector
• TX optical power: 6dBm (XGS-PON), 5dBm (XG-PON), 4dBm(10G EPON)
• RX sensitivity: -28dBm
  Overload optical power: -8dBm
• Transmission distance: 20km
• Wavelength:
  XG(S)-PON:DS 1577nm/US 1270nm
  10G EPON:DS 1577nm/US 1310nm

10G PON layer

• ITU-T G.987(XG-PON)
• ITU-T G.9807.1 (XGS-PON)
• IEEE 802.3av (10G EPON)

User interface

• 1*10GE, Auto-negotiation, RJ45 ports
• 4*GE, Auto-negotiation, RJ45 ports
• 1*USB3.0

USB

1×USB 3.0 for Shared Storage

○ Function Data

O&M

• WEB/TELNET/OAM/OMCI/TR069
• Support private OAM/OMCI protocol and Unified network management of VSOL OLT

Internet connection

Support Bridge/Router mode

Multicast

• IGMP v1/v2/v3, IGMP snooping
• MLD v1/v2 snooping

L2

802.1D&802.1ad bridge, 802.1p Cos,802.1Q VLAN

L3

IPv4/IPv6, DHCP Client/Server, PPPoE, NAT, DMZ, DDNS

Firewall

Anti-DDOS, Filtering Based on ACL/MAC /URL
